Floor Mounted DIY BOX 51.2V 280AH Home Energy Storage System
Quick Detail:
· Easy to Install and Use
· Cost-Effective Energy Solutions
· 8000-Cycle Lifespan
· Protective Class of IP20
· Supports Various Communication Ports
Specifications:
| PRODUCT PERFORMANCE | VP-280 |
| STANDARD VOLTAGE | 51.2V |
| RATED CAPACITY | 280AH |
| OPERATING VOLTAGE | 42V-58.4V |
| STANDARD CHARGING CURRENT | 100A/200A |
| MAXIMUM CHARGE/DISCHARGE CURRENT | 200A |
| OPERATING TEMPERATURE RANGE | 0-40℃(CHARGE) -20-40℃(DISCHARGE) |
| STORAGE TEMPERATURE | -10℃-35℃(1MONTH) 25±2℃(3MONTH)65%±20%RH |
| CYCLE LIFE | 8000 CYCLES @25℃ 50A CHARGE AND DISCHARGE CURRENT 70%STANDARD CAPACITY 80%DOD |
| COMMUNICATION | CAN&RS485 |
| WATER PROOF GRADE | IP20 |
| HUMIDITY RANGE | 5~95% |
| NET SIZE | 898.5*415*260MM |
| NET WEIGHT | 120±3KG |
Description:
Our DIY energy storage kit uses high-quality lithium batteries, which can achieve 8,000 cycles at 70% discharge depth. Integrated intelligent battery management system (BMS), equipped with RS485/CAN bus interface, provides millisecond-level overcharge/over-discharge protection (operating temperature range: 0-40°C (charging) / -20-40°C (discharging). 200A continuous discharge capacity combined with pure sine wave output can perfectly drive high-power equipment such as HVAC. IP20 protection grade housing ensures stable operation in 5%-95% humidity environment. Passed CE / IEC / UN38.3 / MSDS international certification to meet global deployment needs.
Notices:
1. Maintain ambient temperature: 0-40°C (charging), -20-40°C (discharging).
2. Immediately cut off the AC/DC switch when abnormal heating occurs.
3. Do not flush the equipment with water under any circumstances.
4. Maintain 20-80% SoC for cycle life preservation.
5. Recommended to conduct regular inspections and check for loose connections/rust every 6 months.
Applications:
Target applications include autonomous home energy systems, decentralized power installations, vital equipment backup, medical power supplies, and mobile work environment power solutions.
FAQ
Q1 : Are you a manufacturer or a trading company?
A1 : We are manufacturer.
Q2 : Can the BMS be removed and replaced if it breaks? Can the case be opened to replace a bad cell?
A2 : Yes, the case can be opened to replace the BMS & cells on the guidance of engineer.
Q3 : Why should you choose us?
A3 : With 12 international production bases; professional sales team and R&D team; qualified products and competitive prices; timely delivery; sincere service.
Q4 : Is the product original?
A4 : Yes,it is indeed 100% original and authentic, we never sell fake battery, honest is the best policy.
Q5 : How do we control the quality?
A5 : We will make samples before mass production and test them. After sample approved, we will begin mass production. Doing 100% inspection during production and then do random inspection before.
If you have any other questions, please feel free to contact us. Welcome your inquiry .
